imagePROGRAF TA-20
Bring your printing in house with the imagePROGRAF TA-20 large format printer. This multipurpose 24" desktop printer, offers a cost-efficient, easy-to-use solution built to stimulate workflow and productivity for small businesses and first-time large format print users. The TA Series ships with free poster/marketing creation software and a Print Plug-in for Microsoft Office - the software tools you need to bring your business to the next level..
  • UP TO 104 'D' SIZED PRINTS PER HOUR
  • 24" (609MM) PRINT WIDTH
  • 5 COLOUR TD PIGMENT INK SET
  • USB2.0, GIGABIT WIRED, WIRELESS

OVERVIEW

The TA Series ship with 164% more ink than the comparable HP and 157% more ink than the comparable Epson. 330ml ink in total - over a $250 value!

Read More

SOFTWARE

Canon Print Inkjet/Selphy

This is a mobile printing app that enables printing from both iOS and Android devices. You can print large format posters or PDFs straight from your fingertips.

Read More
Specifications
Printer Type

Number of Nozzles

Nozzle Pitch

OS Compatibility



Standard Interfaces



Ink Droplet Size

Ink Capacity

Ink Droplet Size

Color Set

Buffer Ram

Media Width


Media Thickness

Maximum Roll Print Length

Maximum Media Roll Diameter

Paper Feed Method


Languages

Noise Level Approx



Physical Dimensions

Weight

Power Source

Power Consumption



Operating Environment


User-replaceable items


Software Included

5-Color 24-inch Printer

Total: 15,360 - MBK: 5,120 nozzles, C, M, Y, BK: 2,560 nozzles each

1,200 dpi Non-firing nozzle detection and compensation

Windows® 7, 8.1, 10 (32/64bit)
Windows® Server 2008 R2, 2012, 2012 R2, 2016 (64bit)
Macintosh OS X v10.10.5-v10.12x

USB 2.0 High-Speed
10/100/1000 Base-T/TX
Wireless+A56:B69 LAN (IEEE 802.11 b/g/n)

5 picoliter

55ml per color

Pigment Ink

Pigment: Matte Black, Black, Cyan, Magenta, Yellow

2 GB Physical

Cut Sheet - 8"- 17"
Roll Feed - 8" - 24"

0.07-0.8mm

Roll Feed - 59' (18 meters)

5.9 (150mm)

Roll Feed: One Roll, Top-loading, Front
Output Cut Sheet: Top Loading, Front Output

SGRaster, HPGL/2, HP-RTL, JPEG

Operation: 42 dB (A)
Standby: 35 dB (A) or less
Acoustic Power: 5.8 Bels

18“ x 39“ x 30“ (H x W x D)

approx.82 lbs (roll holder included, no inks, no print heads)

AC100-240V (50-60Hz)

Maximum: 52W or less
Standby 3.6W or less
Power Off: 0.3W or less (Compliant with Executive Order)

Temperature: 59°-86° F (15°-30° C) Relative Humidity: 10-80% (No Condensation)

Print Head (PF-06), Maintenance Cartridge (MC-31), Ink Tanks (PFI-030)
Cutter Blade (CT-08)

TA Unified Printer Driver, Accounting Manager, Apple AirPrint, Canon Print Service, Device Management Console, Direct Print & Share, Free Layout Tool, Free Layout Plus, imagePROGRAF Printer Driver for Windows®/Mac®, Media Configuration Tool, Optimized Driver for AutoCAD, Canon PRINT Inkjet Selphy, Easy Photo Print Editor
Call us at 800-567-3222 or contact us for your free quote.
