SureColor S9170 64" Solvent Printer
Expand your perception of what a solvent printer can be. Offering the same extreme colour gamut Epson is known for, the SureColor® S9170 delivers up to 99.5% of PMS Formula Guide Solid Coated (2022 Edition) Full1. With an 11-colour ink set including Red, Orange and an all-new Green, you’ll be able to faithfully reproduce virtually any colour for your customers. Plus, these inks provide extremely fast dry times, allowing for same-day lamination.
- Up to 99.5% of PMS Formula Guide Solid Coated
- 11-colour ink set includes Red, Orange and all-new Green
- All-new space-saving design
- Latest generation PrecisionCore TFP printhead
- First-ever user-replaceable solvent printhead in its class
The SureColor S9170 features a PrecisionCore® TFP® printhead with an integrated temperature sensor control for reliable image quality and consistent colour—job to job, panel to panel. Showcasing the latest generation of innovative Epson technology, it’s the first—ever—user-replaceable printhead in its class3, saving you time and hassle. Created to shift expectations, the SureColor S9170’s sleek, compact, modern design sets it apart—it’s like nothing we've built before.
Overview
- Class-leading image quality — offers the same extreme colour gamut Epson is known for; reach up to 99.5% of PMS Formula Guide Solid Coated (2022 Edition) Full1
- Game-changing UltraChrome® GS3 color ink set — expanded colour gamut with Red, Orange and an all-new Green Ink; extremely fast dry times for same-day lamination2
- Sleek and compact — features an all-new precise and efficient footprint
- Breakthrough design — built with the latest generation PrecisionCore TFP printhead
- Save time and hassle — first-ever user-replaceable solvent printhead in its class3
- White Ink adds versatility and enhances colors — opaque White Ink can be used on clear or dark substrates
- Versatile ink — mix and match ink sizes; 800 mL or 1,500 mL4
- Easy to maintain — automatic daily printhead maintenance
- Advanced software — simple integration to Epson Cloud Solution PORT®5 printer monitoring system
- World-class service and support — 1-year limited warranty included for your peace of mind
Whats in the Box?
- SureColor S9170 Printer
- Set of Ink: C, M, Y, K, Lc, Lm, Lk, Or, R, G, Cl (800 mL/ each)4
- ONYX® Go Plus RIP
- Epson Edge Print Pro RIP
- Power Cord (x2)
- Maintenance Parts Kit: Wiper Unit, Flushing Pad, Air Filter (x2)
- Media Lifter
- Waste Ink Bottle
- Ink Cleaner
- Cleaning Stick
- Media Cleaning Brush
- User Guide Kit
Printing Technology: PrecisionCore Micro TFP printhead featuring Nozzle Verification Technology and variable-sized droplet control
Ink Type: UltraChrome® GS3 eco-solvent ink
Ink Colours: C, M, Y, K, Lc, Lm, Lk, Or, R, G, W or Cl
Nozzle Configuration:9,600 nozzles: 800 nozzles x 10 colors, 1,600 nozzles x 1 color (white)
Maximum Resolution: 1200 x 1200 dpi
Minimum Ink Droplet Volume: Smallest Droplet Size: 4.3 picoliters; Variable Droplet Technology can produce up to three different sizes per line
Left/Right Margin (Roll Paper): 5 mm
Printer Language/Drivers: Epson ESC/P® raster
Memory 1GB
Ink Pack Fill Volume: 800 ml or 1.5 ml
Ink Case: Ink Supply Unit
This printer is designed for use with genuine Epson packs only, not third-party packs or ink*.
Paper Path: Single roll
Paper Feed Method Friction feed
Maximum Roll Diameter 9.84" (250 mm)
Maximum Roll Weight 99.21 lb (45 kg)
Maximum Reel Diameter 7.87" (200 mm)
Paper Width (Roll) 11.81" to 64" (300 mm to 1,625.6 mm)
Paper Thickness (Roll) Less than 1 mm
Printer Interfaces: SuperSpeed USB 3.0 (1 port)
100Base-TX/1000Base-T Ethernet (1 port)
Operating Systems: Windows® 8.1 x64 or later, macOS® 10.7 or later
Epson Edge® Print PRO Minimum PC Requirements: Intel Core® i3 3.0 GHz CPU or faster, 8GB RAM or more, 50GB HDD or more (available during installation), DVD-ROM or Internet connection
ONYX® Go Plus Minimum PC Requirements:
Windows 10 Pro x64 or Windows 11 Pro x64, Intel® or
AMD multi-core CPU, 16GB RAM or more (32GB –64GB
recommended), 1280 x 1024 minimum display,
250GB HDD or more, Internet connection
Control Panel 4.3" Optical Touch Color LCD
Weight and Dimensions (W x D x H)
Dimensions (Printing): 102.2" x 39.2" x 102.2"
(2,620 mm x 1,004 mm x 1,021 mm)
Dimensions (Stowed): 107.9" x 29.9" x 45.1"
(2,620 mm x 925 mm x 1,021 mm)
Weight: 754 lb (342 kg)
Acoustic Noise Level
Sound Power Level: Less than 7.9 B(A)
Sound Pressure Level: Less than 61 dB(A)
Temperature
Operating: 59 ˚F to 95 ˚F (15 ˚C to 35 ˚C)
Operating (Recommended): 68 ˚F to 89 ˚F (20 ˚C to 32 ˚C)
Storage: -4 ˚F to 140 ˚F (-20 ˚C to 60 ˚C)
Relative Humidity
Operating: 20% – 80% (no condensation)
Operating (Recommended): 40% – 60% (no condensation)
Storage: 5% – 85% (no condensation)
Safety Standards
U.S.A. and Canada (NRTL Certified, CSA/UL 62368-1)
Compliant with Class A requirements U.S.A. (FCC),
Canada (ICES-003)
Electrical Requirements
Printer requires two 110 V outlets
Voltage:
#1 AC 100 - 120 V/200 - 240 V (50/60 Hz)
#2 AC 100 - 120 V/200 - 240 V (50/60 Hz)
Rated Current:
#1 12 A/10 A
#2 12 A/10 A
Power Consumption
Operating: Approximately 1190 W
Ready: Approximately 500 W
Sleep: Approximately 3.4 W
Power Off (Stand by): Approximately 0.3 W
Country of Origin
China
